Pylontech 48V 4.8kWh Rack Mount LiFePO4 Battery - US5000-B

Regular price $2,884.44 Sale price$2,596.00
Tax included. Shipping calculated at checkout.

Pylontech US5000-B 48V 100Ah Rack Mounted LiFePO4 Battery Module:

US5000-B is the latest and highest capacity version HESS battery system designed by Pylontech. It’s long life characteristics, highest energy and power density in the industry, fashionable design, easiness of installation and expansion, all reflect the real requirements of end users and the strong technical capability of Pylontech.

Pylontech ensure the highest quality by designing & manufacturing their own Lithium Phosphate (LiFePO4) batteries and BMS boards.

Brochure here

Data sheet here

Manual here

Warranty Guide here

Dimensions (LxWxH): 442x420x161mm

Note: Each Pylontech battery comes supplied with one pair of Amphenol connectors to parallel each battery together. 2000mm pre-wired Amphenol-M8 Lug take off leads are sold separately here


- This compact and modular battery promises more than 6000 cycles with 90% DoD
- The design fits in a battery rack or can be upgraded with custom “feet”
- Deliver up to 9.5KW with single module (for 15 seconds)
- Modular design gives the end customers the power of choice of capacity (up to 16 modules)
- Safest Lithium battery chemistry (Iron Phosphate)
- Compatible with most of the available Hybrid inverters
- Simple buckle fixing minimize the installation time and cost
- Does not require a separate Battery Management Unit
- Safety Cert.TüV CE UN38.3

Additional Features:

- 4RU size (161mm tall)
- Cycle life: >6000 cycles @ 25°C with 95% DoD for daily cyclic applications
- Usable capacity of 4.56kWh @ 48 vDC
- Working Temperature Range -10°C to 55°C, (Charging 0~55°C: Discharging -10~55°C)
- Compact and fashionable 19″ rack design to suit bracket, rack or cabinet installations
- Modular design gives the you the power to design systems from 4.8kWh to a commercial sized 1.704MWh
- Compatible with many available Hybrid inverters
- Backwards Compatible with existing US series products
- Pre-charge function to protect ESS from surge currents
- Safety Cert. CE, UL1973, UKCA, UN38.3, IEC62619, IEC63056
- Communication Protocols: CAN, RS485
- 15+ Year Design Life
- 10 year Warranty
